Citin Gas Combi Boiler 28kW for Heating 180㎡
Brand Citin
Product origin 中国
Delivery time 2025
Supply capacity adequate
Model: L1PB28-3B
Citin Gas Combi Boiler 28kW - Professional Heating Solution for 180㎡ Spaces
| Model: L1PB28-3B | Heating Temperature Range: 30-80℃ | Hot Water Production Capacity(Δt=25℃): 14kg/min |
| Power: 28kW | Gas Consumption(Min to Max): 0.9-2.9m³/h | Hot Water Production Capacity(Δt=30℃): 12kg/min |
| Thermal Efficiency: 90% | Domestic Hot Water Pressure: 0.02-0.6Mpa | Heating for Water Pressure: 0.1-0.3Mpa |
| Power Supply: 220V/50Hz | Minimum Water Flow: 3.24L/min | Scope of Heating: 140-180㎡ |
| Chimney Diameter: 60/100mm | Dimensions: 740*410*310mm | DHW Temperature: 30-60℃ |
Smart Dual-Function Gas Combi Boiler
Engineered for commercial/residential applications, this 28kW Gas Boiler achieves 90% thermal efficiency in simultaneous space heating
and DHW production. The Gas Combi Boiler's intelligent modulation automatically adjusts gas consumption (0.9-2.9m³/h) for 140-180㎡
heating areas.
Key Technical Highlights
Precision Gas Combustion Control: 5-stage adaptive valve maintains 30-80℃ heating temps (±1℃)
High-Flow Combi Boiler Performance: 14kg/min DHW at Δt=25℃ (12kg/min at Δt=30℃)
Dual Pressure System: Mechanical manometer + digital sensors monitor 0.1-0.3MPa (heating)/0.02-0.6MPa (DHW)
Optimized for Search Visibility
✓ Gas Combi Boiler with LED display & rotary controls
✓ Citin Gas Combi series' space-saving 740×410×310mm chassis
✓ 28kW Gas Boiler ideal for 180㎡ commercial/residential projects
Professional-Grade Design
• Crisp White Gas Boiler Housing: Scratch-resistant finish (IPX4 rated)
• Hybrid Interface: Tactile knobs + LED screen + analog manometer
• Tool-Free Access: Panel with 60/100mm chimney options
